The Acuity is provided with a Full HD (1080p) camera and display as standard, giving the user a very sharp and stable image along with a very wide viewing angle. The XY-table offers space for A3 reading material and incorporates our unique Magnetic Lines technology, ensuring the reader will never lose track of their text.
The device switches to Speech mode with a simple switch and can read the text aloud. It automatically recognizes the languages, so it will pronounce the words with the correct voice.
For use in the office environment, for example, the external HDMI input can be used to use the Acuity as a computer screen. The Acuity has even the ability to apply High contrast colours over this image.
Main Specifications
- Acuity Basic / Acuity Basic Switch
- 22-inch widescreen display
- 1080p, 1920x1080, FullHD resolution,
- 50Hz or 60Hz refresh rate
- 178° horizontal and vertical viewing angles
- Touchpad technology in the display
- Height and tilt adjustable monitor
- 2.3x up to 65x magnification
- 1x magnification in crop mode
- A4 page width visible in the lowest magnification
- 2 photo modes (full colour, monochrome)
- Up to 10 high-contrast modes
- Reflection-free and shadow-free uniform LED lighting
- Autofocus and fixed-focus camera modes
- A3 page wide XY-table with horizontal and vertical brake
- Magnetic lines in XY-table
- A total solution of 16 kilograms
- One box solution, plug-and-play
- Three control methods are available:
- Touchpads (optional reference frame and tactile buttons available)
- Direct multi-touch touchscreen input
- Separate remote control
Display
| Display Size | 22 inch (54.6 cm) |
| Resolution | 1920x1080 (1080p, full HD) |
| Video refresh rate | 50Hz or 60Hz |
Magnification
| Maximum | 65x |
| Minimum | 2.3x |
| Minimum in crop mode | 1x |
Functionality
| Display mode - Photograph | A. Full colour (or High saturation)B. Grayscale | |
| Display mode - High contrast | C. Black/whiteD. White/blackE. Black/YellowF. Yellow/blackG. Blue/Yellow | H. Yellow/BlueI. Black/GreenJ. Green/BlackK. Black/RedL. Red/Black |
| Reading Aid | Horizontal Reading LineVertical Reading LineHorizontal block blankingVertical block blanking | |
| External inputs | 2x HDMI (display modes changeable) | *For Switch models only |
| preferred input resolution | 1920x1080 | |
Power supply
| Power | input: 100-240VAC, 50/6-Hz, 1.5A output: 12VDC / 4A consumption: standby: 0.2W Max: 48W. |
|---|
Operating conditions
| Temperature | 5 °C - 40 °C41 °F - 104 °F |
|---|---|
| Humidity | <75% (no condensation) |
Storage and transport conditions
| Temperature | -25 °C - 70 °C-13 °F - 158 °F |
|---|---|
| Humidity | <90% (no condensation) |
Package contents
- Acuity Basic (device)
- Power Adaptor
- Power cord
- User manual
- Acuity training Doming Label
Size and weight
- size: 48 × 48 × 65 cm (screen in highest position)
- Weight: 17kg
